6305-2RZ · SKF 6305-2RZ deep groove ball bearing

SKF 6305-2RZ single-row deep groove ball bearing with two non-contact NBR seals. Reference and limiting speeds are separate catalog ratings.

Technical specifications

Bore diameter

25 mm

Outside diameter

62 mm

Width

17 mm

Dynamic load rating

23.4 kN

Static load rating

11.6 kN

Weight

0.23 kg

Technical source documents

• SKF · SKF catalog table, PDF page 63, designation 6305-2RZ
• SKF · Partial review 2026-10-15: rMin, calculationFactorF0, cageMaterialEn, cageMaterialFa, clearanceOptions, sealingEn, sealingFa, descriptionEn, descriptionFa. SKF deep groove ball bearings, Japanese catalog excerpt, section 1.2. See per-field pages and unresolved items in catalog review ledger; this date does not verify the whole product.
