6206-2RZ · SKF 6206-2RZ deep groove ball bearing

SKF 6206-2RZ single-row deep groove ball bearing with two non-contact NBR seals. Reference and limiting speeds are separate catalog ratings.

Technical specifications

Bore diameter

30 mm

Outside diameter

62 mm

Width

16 mm

Dynamic load rating

20.3 kN

Static load rating

11.2 kN

Weight

0.2 kg

Technical source documents

• SKF · SKF catalog table, PDF page 65, designation 6206-2RZ
• SKF · Partial review 2026-10-15: rMin, calculationFactorF0, cageMaterialEn, cageMaterialFa, clearanceOptions, sealingEn, sealingFa, descriptionEn, descriptionFa. SKF deep groove ball bearings, Japanese catalog excerpt, section 1.2. See per-field pages and unresolved items in catalog review ledger; this date does not verify the whole product.
